100 - 240VAC Ultra-thin Industrial Lighting Fixture Parts 18mm , High Efficiency SEC-N-QD108

Brand Name : GPT

Model Number : SEC-N-QD108

Certification : CE RoHS

Place of Origin : China

MOQ : 200PCS

Supply Ability : 10,000pcs per month

Delivery Time : 30 days

Packaging Details : Standard export packing

Model : SEC-N-QD108

Input : 100-240V 50-60Hz

Watt : 40W / 60W / 100W

IP : 65

PF : 0.98

Lifetime : 50,000 hours

Contact Now

100 - 240VAC Ultra-thin Industrial Lighting Fixture Parts 18mm , High Efficiency SEC-N-QD108

Description:

  • Constant voltage LED driver
  • Output power: 40W/60W/100 Max
  • Input Voltage:100-240VAC
  • Constant voltage ouput : 12VDC
  • Thickness: 18mm
  • Open ciricuit, short circuit protection
  • Over-load, over temperature protection
  • Efficiency: >94% (AC230V, full load)
  • High PF above 0.98

Specification:

CC/CV

Watt

(W)

CV Output

(V)

Ta

Tc

PF

Size

CV

40

12VDC

-20～65℃

85℃

0.98

192x62x18mm

CV

40

24VDC

-20～65℃

85℃

0.98

192x62x18mm

CV

60

12VDC

-20～65℃

85℃

0.98

212x62x18mm

CV

60

24VDC

-20～65℃

85℃

0.98

212x62x18mm

CV

100

12VDC

-20～65℃

85℃

0.98

242x62x18mm

CV

100

24VDC

-20～65℃

85℃

0.98

242x62x18mm

Size:

40w:

60w:

100w:

Standard:

Safety compliance-EN61347

EMC compliance- EN55015, EN61000,EN61547

EMF compliance-EN62493

Competitive advantage:

  • Ultra-thin driver, thickness only 18mm
  • IP65 proction level
  • 5 years warranty
  • Open circuit, shot circuit, over load, over temperature protection
  • High PF above 0.98
