30W / 33W / 35W Commercial Lighting Fixture Led Spotlight Track Light Bridgelux Brands

Product Categories
Shining Electronic CO., LTD
Contact Now

30W / 33W / 35W Commercial Lighting Fixture Led Spotlight Track Light Bridgelux Brands

Brand Name : SHINING

Model Number : SEC-L-DG104

Certification : CE, TUV

Place of Origin : CHINA

MOQ : 100

Payment Terms : T/T OR L/C

Supply Ability : 30000PCS PER MONTH

Delivery Time : 5~7days for samples,25~30days for order production

Packaging Details : STANDARD EXPORT PACKING OR OEM

Material : Aluminum

Power : 30 W

Led Chip : Bridgelux

Beam Angle : 15°,60°

Model : SEC-L-DG104

Appoximitate : 2000lm/3000lm

Contact Now

30W / 33W / 35W Commercial Lighting Fixture Led Spotlight Track Light Bridgelux Brands

Quick Detail:

  • 1- LED track light
  • 2- Model no. SEC-L-DG104
  • 3- Power: 25W/38W
  • 4- Appoximitate: 2000lm/3000lm
  • 5- Beam angel:10°,24°,45°
  • 6- CRI＞80
  • 7- CCT: 2700K/3000K/4000K/5000K
  • 8- Certificate: CE /ROHS
  • 9- Class protection: IP20
  • 10- Application: Store lighting, Furniture lighting, Furniture lighting, Office lighting, Supermarket lighting, Signage lighting,
  • Model Number :SEC-L-DG104

Description:

Model SEC-L-DG104
Power 30 W: kl0% 33W±10% 35W: fcl0%
Input voltage Non-Dimmable 　 AC100-240V 50/60HZ. AC200-240V 50/60HZ 　
LED Current DC 800mA DC 900mA DC 900mA
Light source COB LED
CCT 2700K/3000K/4000K/5000K
Beam Angle 15°/20* /24° MO* /60°
　 Beam Angle 15° 60° 15° 60° 15° 60°
　 2700K 1980 lm±5% 1755 lm±5% 2330 lm±5% 2008 lm±5% 2932 lm±5% 26311m ±5%
　 3000K 2080 lm±5% 1835 lm±5% 2450 lm±5% 2080 lm±5% 3020 lm±5% 2683 lm±5%
　 4000K 2185 lm±5% 1850 lm±5% 2570 lm±5% 2320 lm±5% 3171 lm±5% 2820 lm±5%
　 5000K 2385 lm±5% 2210 lm±5% 2810 lm±5% 2350 lm±5% 3330 lm±5% 2950 lm±5%
　 2700K 17500 cd±5% 2134 cd±5% 20545 cd±5% 2655 cd±5% 21900 cd±5% 3550 cd± 5%
Imax 3000K 18500 cd±5% 2237 cd±5% 21820 cd±5% 2800 cd±5% 23000 cd±5% 3620 cd± 5%
　 4000K 19000 cd±5% 2345 cd±5% 22400 cd±5% 3065 cd±5% 24140 cd±5% 3804 cd± 5%
　 5000K 20100 cd±5% 2765 cd±5% 23970 cd±5% 3100 cd±5% 25300 cd±5% 3995 cd± 5%
Surface Color 　　White/Black　　　

Applications:

  • This Product is in the category of "Spotlights" or "LED Spotlights ".
  • It can be used in following applications:

Commercial Lighting,
Display Lighting
